STS DLMS Prepaid E electricity Meters with Intelligent Technology(GPRS/GSM)


STS DLMS Prepaid E electricity Meters with Intelligent Technology(GPRS/GSM)


The CA168 is used for a wide rang of smart metering applications. It combines latest3DES Securityencryption technology and modu- lar communication unit. The meter is allowing a basic current of5 Amp while retaining a maximum current of80 Amp and extended AMR/AMI functional features. It is a compact design in a BS8565 standard housing and maintains the rugged RF immunity with- stand of30vm and ip54 rating, allowing it to operate in harsh envi- ron ments.
The meterworks with a plug-in module forDLMS/COSEM Compliantdata collection and network communi- cations. This modular design enables utility to select from PLC/RF/GPRS/3G and 4G LTE Cellular data networks according to local conditions at low cost. upgrade and maintenance will also become cost-effec- tive by replacing the modules only instead ofthe entire meter.


Main Features
o DLMS/COSEM Standard compliant
20 digit (standard Transfer specification) STS encryption
o IEC62056 -21 compliant optical&RS485 port allowing for easy data interrogation Disconnects on overload and no credit
prepayment and credit mode hot swap
DISCAAA9 et IEC 62055-52 available on request
Detection and record tamper event such as opening cover, reverse connection , black-out


user Benefit
o Easy connection to user Interface unit (ulu) for split type applications
o PLC/ RF / GPRS Communication with a head-end AMR/AMI Server
o Time of use (TOU) , multi-tariff, holidaysetting · o Advanced load control and disconnection
features



Quality STS DLMS Prepaid E electricity Meters with Intelligent Technology(GPRS/GSM) for sale
